USED – PROTO-1 Ram End Forming and Tube Cut off

Model:  RAM-70
Year: 2002

240 3 Phase – 20 HP

70 ton 7 position progressive ram end forming and tube cut-off machine for tube and pipe from 0.125’’- 7.0’’ diameter. Ram-70 has tube cut-off capability for after bend.  Proto-1’s tube cut-off technology is industry leading and allows for a quick cut-off resulting in no burr’s. Proto-1’s RAM-70 End Form Applications: offset expands, coping, piercing, trim/form, tube reducing, bending, swaging, spline, slotting, hole punch, beading, flaring, notching, and large bead.

 SPECIFICATIONS

• Tube Diameter: .125″ – 7.0″
• Tube Wall: .020″ – .120″
• Cycle Time: Depends on tooling and material
• Hydraulic Cylinders Clamp (70 ton vertical with 8″ bore and 18″ stroke)
• Hydraulic Cylinders Ram (70 ton horizontal with 8″ bore and 14″ stroke)
• Dimensions: 138.9″ length x 96.6″ width x 114.1″ height

Safety Features

• Light curtains – Minisafe
